• Compact design
• SS316L wetted parts & 17/4PH Tip material provided for better corrosive resistance
• Non rotating stem design for self centring & avoid galling issue
• Heat treated stem provides better shut –off
• Self lubricating Aluminium bronze housing reduce operating torque
• PTFE packing provide positive leak free sealing
• Packing below thread to avoid lubricant wash out
• Re adjustable packing method for long life
• Locking clamp avoid accidental removal of housing during operation
• Supply to NACE MR 0175 / ISO 15156, if required
• Panel mounting external hole provision provided
• Safety weep hole for all pressure connection area

Tube OD Inch (mm) | Port thread Inch (mm) | Hole size Inch (mm)

1/4(6.35) | 9/16 - 18 | 0.09(2.3)
3/8(9.53) | 3/4 - 16 | 0.125(3.3)
9/16(14.3) | 11/8 - 12 | 0.189(4.7)

• Wetted parts – SS 316 / SS316L
• Non rotating lower stem – 17/4 ph
• Glass filled PTFE

- 29°C to 210°C ( -20.2°F to 410°F )

30000 psi Max ( 2068 Bar Max)

100% Hydro testing performed using water
(Shell test – 1.5 T of CWP & Seat test – 1.1 Times of CWP)

EN10204 – 3.1 Certification will be provided, if required
