• Suitable for service upto 45000 psi
• Used to streamline the fluid & compressed air distribution and enhancing system efficiency
• Reduce the complexity of multiple connection and potential leak path
• More cost effective
• Available with needle valve / ball valve
• Low maintenance cost
• Less space consumption
• Reduce the installation lead time
• Reduce the labour cost
• Excellent flow
• Available with various end connections ( Screwed end (npt / bspp / bspt) / tube od end / compression end / welded end / flanged end)
• Supply to NACE MR 0175 / ISO15156, if required
• Npt threads as per Std B1.20.1
• Flanged end as per ASME B16.5 Std

1/4 “ to 1” – NPT / BSPP / BSPT (Male or Female) - Upto 15000 psi
1/4 “ to 1 ” – TUBE OD & COMPRESSION ENDS - Up to 45000 psi
1/2” to 2” – FLANGED / WELDED END - Up to 6000 psi

316/316L -STAINLESS STEEL – Standard construction
(Other materials- Upon customer requirement)

-29°C to +200°C ( -20.2 °F to +392°F)

45000 PSI ( 3100 Bar) Max

100% Hydro testing using water with 1.5 times of maximum
working pressure.

EN10204 – 3.1 Certification
EN10204 – 3.2 Certification will be provided if required
